Features of MGL2-100-TPE

1. Reliability
-By adopting a torque arm with a built-in vibration isolation mechanism, the bearing and Reduction gear are protected and the life is extended (1.5 to 2 times that of our company).
Rotation a dedicated large rotary blade prevents darkening that occurs when passing through the casing.

2. Cleanability
-The housing can be fully opened without tools by adopting a pivot link opening / closing mechanism.
-A round head bolt is used to Fitting the fixed blade, so there is no clogging of the Regrind material in the bolt head.

3. Maintainability
-A viewing window is standard equipment so that the Grind state can be visually observed.
-The dust wiper with a reverse screw mechanism prevents fine powder from entering the bearing. You can also Manual operation purge the air.

4. Safety and factory environment
・Three limit switches are attached to the input hopper opening and closing part and the suction box insertion part for interlock.
・Equipped with a motor breaker as standard for overload protection.
・In order to prevent bridging in the feeding hopper of the sprue runner, a straight feeding hopper has been adopted.
